体验下linkerd

简介

和大部分服务网格一样,linkerd分为控制平面和数据平面

安装linkerd cli

wget https://github.com/linkerd/linkerd2/releases/download/edge-22.10.3/linkerd2-cli-edge-22.10.3-darwin-arm64

chmod +x linkerd2-cli-edge-22.10.3-darwin-arm64

mv linkerd2-cli-edge-22.10.3-darwin-arm64 bin/linkerd

检查你的k8s连接状态

kubectl get pods -A

预先检查下环境

linkerd check --pre

如果都ok,那么输出应该类似于下面

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Linkerd core checks
===================

kubernetes-api
--------------
√ can initialize the client
√ can query the Kubernetes API

kubernetes-version
------------------
√ is running the minimum Kubernetes API version

pre-kubernetes-setup
--------------------
√ control plane namespace does not already exist
√ can create non-namespaced resources
√ can create ServiceAccounts
√ can create Services
√ can create Deployments
√ can create CronJobs
√ can create ConfigMaps
√ can create Secrets
√ can read Secrets
√ can read extension-apiserver-authentication configmap
√ no clock skew detected

linkerd-version
---------------
√ can determine the latest version
√ cli is up-to-date

Status check results are √

安装控制平面

安装crd

linkerd install --crds >crd.yaml

linkerd install --crds | kubectl apply -f -

安装控制平面

linkerd install > res.yaml

linkerd install | kubectl apply -f -

检查安装状态

linkerd check

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
Linkerd core checks
===================

kubernetes-api
--------------
√ can initialize the client
√ can query the Kubernetes API

kubernetes-version
------------------
√ is running the minimum Kubernetes API version

linkerd-existence
-----------------
'linkerd-config' config map exists
√ heartbeat ServiceAccount exist
√ control plane replica sets are ready
√ no unschedulable pods
√ control plane pods are ready
√ cluster networks contains all node podCIDRs
√ cluster networks contains all pods
√ cluster networks contains all services

linkerd-config
--------------
√ control plane Namespace exists
√ control plane ClusterRoles exist
√ control plane ClusterRoleBindings exist
√ control plane ServiceAccounts exist
√ control plane CustomResourceDefinitions exist
√ control plane MutatingWebhookConfigurations exist
√ control plane ValidatingWebhookConfigurations exist
√ proxy-init container runs as root user if docker container runtime is used

linkerd-identity
----------------
√ certificate config is valid
√ trust anchors are using supported crypto algorithm
√ trust anchors are within their validity period
√ trust anchors are valid for at least 60 days
√ issuer cert is using supported crypto algorithm
√ issuer cert is within its validity period
√ issuer cert is valid for at least 60 days
√ issuer cert is issued by the trust anchor

linkerd-webhooks-and-apisvc-tls
-------------------------------
√ proxy-injector webhook has valid cert
√ proxy-injector cert is valid for at least 60 days
√ sp-validator webhook has valid cert
√ sp-validator cert is valid for at least 60 days
√ policy-validator webhook has valid cert
√ policy-validator cert is valid for at least 60 days

linkerd-version
---------------
√ can determine the latest version
√ cli is up-to-date

control-plane-version
---------------------
√ can retrieve the control plane version
√ control plane is up-to-date
√ control plane and cli versions match

linkerd-control-plane-proxy
---------------------------
√ control plane proxies are healthy
√ control plane proxies are up-to-date
√ control plane proxies and cli versions match

Status check results are √

安装Viz扩展

linkerd viz install>viz.yaml

linkerd viz install|kubectl apply -f -

等viz扩展的相关pod都启动完成之后,查看dashboard

linkerd viz dashboard

安装演示程序

wget https://run.linkerd.io/emojivoto.yml

kubectl apply -f emojivoto.yml

注入数据平面组件

使用cli注入

1
2
3
kubectl get -n emojivoto deploy -o yaml \
  | linkerd inject - \
  | kubectl apply -f -

或者直接在你的deployment或者namespace中添加annotations

1
2
      annotations:
        linkerd.io/inject: enabled

卸载

删除示例程序

1
2
3
kubectl get -n emojivoto deploy -o yaml \
  | linkerd uninject - \
  | kubectl apply -f -

kubectl delete -f emojivoto.yml

卸载viz扩展

linkerd viz uninstall | kubectl delete -f -

卸载linkerd

linkerd uninstall | kubectl delete -f -
